Glass Fiber Reinforece lightweight Panels Production Line Board Making Machine EPS Concrete Wall Panel Making Machine

FOB Reference Price:Get Latest Price
US$15,000.00 - US$25,000.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
EPS concrete lightweight wall panel
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 25 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Warranty:
2 Years
Production Capacity:
50000 to 300,000m3 per year
Power(W):
4kw
After-sales Service Provided:
Online support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Engineers available to service machinery overseas
Applicable Industries:
Building Material Shops, Manufacturing Plant, Retail, Construction works , Energy & Mining
Condition:
New
Application:
EPS Lightweight Sandwich Panel
Automatic Grade:
Automatic
Place of Origin:
Guangxi, China
Brand Name:
HONGFA
Voltage:
220v/380v
Dimension(L*W*H):
3380*3200*2680mm
Weight:
7200kg
Features:
Hydraulic Pressure
Certification:
ISO CE
Key Selling Points:
High-accuracy
Raw materials:
Cement
Product name:
Lightweight Wall Panel Machine
Name:
Concrete Lightweight Wall Panel Machine
Use:
Partition Wall Panels
Advantage:
Environment Friendly
Materials:
Cement Perlite Fly Ash
Supply Ability
Supply Ability:
800 Set/Sets per Year Light Weight Wall Blocks Making Machine
Packaging & Delivery
Packaging Details
Sea Worthy Package for GFRG Glass Fiber Reinforece lightweight Panels Production Line Board Making Machine EPS Concrete Wall Panel Making Machine
Port
Qinzhou
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 25 To be negotiated
Video Description

Glass Fiber Reinforece lightweight Panels Production Line Board Making Machine EPS Concrete Wall Panel Making Machine



What are the EPS Concrete Lightweight Wall Panel?



EPS concrete sandwich wall panel is a new type of building material. It is one of the light weight wall panel material with EPS mortar as core material, and the two surface are the skin board made by calcium silicate board or fiber cement board. It is the new type composite EPS concrete lightweight wall panel. This sandwich concrete EPS lightweight wall panel is composed of high strength water resistant calcium silicate board with good waterproof properties and good thermal insulation EPS bonding mortar as core material.





The raw materials to make EPS concrete lightweight wall panel.



The project with the sandwich EPS concrete lightweight wall panel is stressed to wall lightweight, high strength, thermal insulation, waste utilization, energy conservation and other functions.Therefore, the implementation of the project is imperative. The panel can meet the requirements of the modern building standard.







What are the EPS concrete lightweight wall panel features and applications?


This EPS concrete lightweight wall panel is of structural function , waterproof and thermal insulation performance, mainly used as building wall partition. This kind of EPS Sandwich Wall Panel is provided with comprehensive advantage that other wall panel can't compare with: solid, lightweight, thin body, high strength, impact resistance, strong hanging force, heat insulation, sound insulation, fire prevention, waterproof, easy cutting, can be arbitrary slot, without rendering coat, dry decoration, environmental protection. At the same time, this kind of building material sandwich concrete EPS lightweight wall panel also can reduce wall occupying space, increase the rate of using residential space, reduce structure load, promote building anti-seismic ability and safety performance, reduce the comprehensive cost.



Glass Fiber Reinforece lightweight Panels Production Line Board Making Machine EPS Concrete Wall Panel Making Machine




What machines to make EPS concrete lightweight wall panel?



1. Hongfa manual vertical EPS concrete lightweight wall panel making machine.

This sandwich concrete dry wall panel is in low investment and highest capacity. This kind of sandwich lightweight wall panel machine can be considered due to the limit of functional requirements.






It can make the sandwich concrete lightweight eps sandwich wall panel with the size: length 2270/2440/3000mm, width 610mm, thickness 60-200mm (size and thickness can be adjusted).



2. Hongfa horizontal type EPS wall panel making machine



This EPS wall panel making machine is automatic type, easy operation and less workers. The automatic horizontal concrete eps wall panel production line features high precise injecting, good controls on the temperature and raw material mixing, and keeping well with the foamed material equal wrapping and prevents the bead agglomerate because of the bad temperature control.








It can make the sandwich ligthweight dry wall panel with the size: length 2270/2440/3000mm, width 610mm, thickness 60-200mm (size and thickness can be adjusted).





Glass Fiber Reinforece lightweight Panels Production Line Board Making Machine EPS Concrete Wall Panel Making Machine

3: Hongfa automatic vertical concrete EPS sandwich wall panel making machine.



The EPS lightweight wall panel machine is specializing in the production of light weight wallboard which has a flat surface, smooth and high density and this production line realizes the industrial requirements of the new building partition panel material. It is automatic operation, high capacity and with fewer workers. This Hongfa exclusive EPS sandwich dry wall panel machine is designed with simple and reliable operation, mature and stable equipment and technology. The EPS lightweight wall board building machine greatly reduces the labor intensity of production workers and improve wall panel EPS production efficiency.








It can make the lightweight cement dry block wall with the size: length 2270/2440/3000mm, width 610mm, thickness 60-200mm (size and thickness can be adjusted).



The advantages of lightweight EPS wall panel making machine:



- This concrete light weight sandwich wall panel machine is with high precise guiding pressure reducing valve controls the temperature and steam pressure of the closed barrel.

- This sandwich cement eps wall panel machine is with photoelectric or vibration sensor to control material level, ensuring density tolerance within ±3%.



- This concrete EPS sandwich panel machine adopts PLC and touch screen control, automatic filling, electronic weighing, temperature control, material level control to realize automatic production.

 Our HONGFA Services For EPS Wall Panel Machine Projects





Pre-Sales Service

* Free inquiry and consulting support for the for the concrete EPS wall panel production line.

* Analyze customers' needs and market prospect.

* View our Factory for the concrete EPS wall panel machine

* Provide perfect solution to set up a factory to perform sandwich eps wall panel making machine operation.

After-Sales Service

* One year guarantee for the sandwich lightweight wall panel making machine.

* Engineers available to service machinery overseas with concrete EPS sandwich light weight wall panel machine installation, training and maintenance.

* Supply free consultation and parts services for the sandwich eps lightweight wall panel making machine.

Our Company - Hongfa Machinery





Glass Fiber Reinforece lightweight Panels Production Line Board Making Machine EPS Concrete Wall Panel Making Machine

Who We Are?


Guangxi Hongfa Heavy Machinery Co., Ltd., is located at Yin Ling Yan Industrial Zone in Nanning, which is well-located and easy of access. The company is the biggest and most abundant technical force, and best-quality professional manufacturer of brick making machinery and construction machinery in the Southwest of China. Our business range are R&D, produce and sell new walling material equipments “Hongfa” brand AAC block production line, concrete batching plant, full automatic concrete block making machine, concrete tile making machine, concrete pipe making machine,concrete sandwich dry wall panel making machine, isostatic press machine and mining machinery, pvc pallets, etc.



All of our Hongfa products compliance with the national implementation of standards and approved by ISO9001-2000 international quality certificate. Our products sell well all over the country, and exporting to the United States, Russia, Australia, Brazil, India, Vietnam, Thailand, Sultan, Korea, more than 120 countries and regions. Our products are deeply welcome by domestic and foreign customers. Hongfa Group is committed to building strong client relationships and assisting our clients to achieve their ultimate strategic objectives.


Owning over 67 patents (including invention and practical patents) and gaining “China Well-Known Trademark” honor, Hongfa Machinery is dedicated to providing high quality EPS light wight wall panel making machines to our customers.



Packing & Delivery for Lightweight EPS Wall Panel Making Machine



Packing Details  : Sea Worthy Package

Delivery Details :  20~30 days after order confirmed





Our Hongfa Certifications





Glass Fiber Reinforece lightweight Panels Production Line Board Making Machine EPS Concrete Wall Panel Making Machine

High Quality Guarantee

Owning over 67 patents (including invention and practical patents) and gaining “China Well-Known Trademark” honor, Hongfa Machinery is dedicated to providing high quality EPS light wight wall panel making machines to our customers.



FAQ



Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: 20 days after receipt of deposit and molds confirmation from Buyer.

Q: What is the product guarantee period ?
A: One year after installation finished at buyer's factory.

Q: What is your terms of payment ?
A:  Payment:30% as down deposit by T/T ,70% as the balance paid before loading



Note: The video EPS lightweight sandwich panel making machine is available for you, please contact me now.
